- Image Sensor 1/2.7” 5MP CMOS Image Sensor (0.9407cm)
- Minimum Illumination 0.02 Lux/F2.0, 30IRE, 0 Lux IR on
- Shutter Speed PAL: 1/25s–1/100000s ; NTSC: 1/30s–1/100000s
- White Balance Auto / Manual
- Gain Control (AGC) Auto / Manual
- Max. Aperture F2.0
- Lens 3.6mm (2.8mm optional)
- Max Aperture F2.0
- Iris Fixed
- Lens Type Fixed lens/ Fixed Iris
- Close Focus Distance 2.8 mm: 0.8 m ; 3.6 mm: 1.2 m
- Privacy Mask Off / On (8 area, rectangle)
- Audio Built-in Mic
- Back Light Compensation BLC / HLC / DWDR
- Video Streaming CVI: PAL: 5MP@25fps; 4MP@25fps; 1080P@25fps; NTSC: 5MP@25fps; 4MP@30fps; 1080P@30fps; AHD: PAL: 4MP@25fps; NTSC: 4MP@30fps; TVI: PAL: 4MP@25fps; NTSC: 4MP@30fps; CVBS: 960H
- Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Angle of View 3.6 mm: 104° × 88° × 46° (D × H × V); 2.8 mm: 125° × 106° × 56° (D × H × V)
- IR IR Range of 20 Mtr., Smart IR
- Casing Plastic
- Power Source 12V DC ±30%
- Power Consumption Max 3.7W (12V DC, IR on)
- Weatherproof Standard IP6
DVR DETAILS
- IP Camera Input 8+4 Ch. : each channel up to 8MP
- Two-way Talk Reuse audio in/out, RCA
- User Interface GUI
- Video Output 1 HDMI, 1 VGA
- Video Resolution HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720, VGA: 1920×1080, 1280×1024, 1280×720
- Video Compression Instastream/H.265/H.264+/H.264
- Video Display Split 1/4/8/9
- Video Channel 8 channel, BNC
- Video Standard Analog: NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
- Audio Output 1 channel, RCA
- Audio Channel 1 channel, RCA
- Motion Detection MD Zones: 396 (22 × 18)
- Video Loss Supports
- Smart Phone iPhone, iPad, Android Phone
- Hard Disk 1 SATA port, up to 10TB
- Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
- Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
- Backup Mode USB Device/ Network
- Max User Account 128 users
- Record Interval 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Ethernet 1 RJ-45 port (1000M)
- Interface Ports 1 HDMI, 1 VGA, 2 USB Ports(1 USB 2.0, 1 USB 3.0), 1 RS485
- Power Supply DC12V/2A
- Power Consumption <10W(without HDD)
- Dimension 260mm×236mm×48mm
